在油煙凈化器的放電電場異極間具有10-15千伏特的電位差，使不導電的氣體分子經分解或電子附著成為自由離子。當氣流通過收塵電場區域時，粒子經離子撞擊帶電而移向具相反電性的收集電極。換言之，收集機制的步使氣體離子化，第二步使氣流中的粒子帶電。第三步使粒子撞擊收集電極板而被收集。

　　In a soot purifier, the electric field of the soot purifier has a potential difference of 10-15 kV between the poles of the soot purifier, so that the free gas molecules are decomposed or electronically attached to free ions. When the airflow passes through the dust collecting electric field, the particles move electrically to the collecting electrode with the opposite electrical charge. In other words, the first step in the collection mechanism is to ionize the gas, and the second step is to make the particles in the stream live. The third step is to cause particles to hit the collecting electrode plates and to be collected.

　　理論上，分離帶電粒子的電力與粒子帶電量及收集電場強度之積成正比。此電力的大小，就比重為1的l微米粒子而言，為重力的3000倍：就比重為l的10微米粒子面言，為重力的300倍，此為油煙凈化器能與率的原因。

　　In theory, the power of a charged particle is proportional to the amount of charged particles and the strength of the electric field gathered. The size of the power is 3000 times the gravity of the L micron particle with a specific weight of 1: the 10 micron particle size of L is 300 times the gravity, which is the reason for the high efficiency and high efficiency of the soot purifier.

　　1、電場模塊化設計制作，組合方便，可按風量拼裝成型，拆裝便利，檢修方便。

　　1. The electric field modular design makes, the assembly is convenient, may assemble by the air volume, the assembly and disassembly is convenient, the overhaul is convenient.

　　2、的電場設計，精密、牢固的蜂窩式電場結構，360度無死角，使電場與油煙粒子結合作用的時間更長，凈化更完全。

　　2, advanced electric field design, precise and firm honeycomb type electric field structure, 360 degrees without dead angle, make electric field combine with lampblack particle longer, purify more completely.

　　3、進出風口可隨意互換，方便現場安裝需要(出廠時機器的進出風口已經設置好，如

　　3. The air inlet and outlet can be interchanged at will. It is convenient for installation on site. (factory) the air inlet and outlet of the machine have been set up, such as

　　有需調配時請參考安裝方法)。

　　Please refer to the installation method when it is necessary to deploy.

　　4、采用撞針式連接，系數高，更好的高壓連接設計，開門時電場會自動斷電。

　　4, the firing pin type connection, high safety coefficient, design a better connected pressure, open the door when the electric field will automatically power off.

　　5、凈化效率高，運行穩定，去除率高于85%，能去除大部分氣味。

　　5, high purification efficiency, stable operation, removal rate is higher than 85%, can remove most of the odor.

　　本文由油煙凈化器為您提供，我們的網站是:http://www.sjdysx.com/我們將以全心全意的熱情為您提供更的服務，歡迎您的訪問!

　　This article is provided by the lampblack purifier, our website is: http://www.sjdysx.com/, we will wholeheartedly provide you with better service, you are welcome to visit!
